Class definition for the storage engine. More...
#include <ha_example.h>
Public Member Functions | |
| ha_example (handlerton *hton, TABLE_SHARE *table_arg) | |
| const char * | table_type () const |
| The name that will be used for display purposes. | |
| const char * | index_type (uint inx) |
| The name of the index type that will be used for display. Don't implement this method unless you really have indexes. | |
| const char ** | bas_ext () const |
| The file extensions. | |
| ulonglong | table_flags () const |
| This is a list of flags that indicate what functionality the storage engine implements. The current table flags are documented in handler.h. | |
| ulong | index_flags (uint inx, uint part, bool all_parts) const |
| This is a bitmap of flags that indicates how the storage engine implements indexes. The current index flags are documented in handler.h. If you do not implement indexes, just return zero here. | |
| uint | max_supported_record_length () const |
| unireg.cc will call max_supported_record_length(), max_supported_keys(), max_supported_key_parts(), uint max_supported_key_length() to make sure that the storage engine can handle the data it is about to send. Return real limits of your storage engine here; MySQL will do min(your_limits, MySQL_limits) automatically. | |
| uint | max_supported_keys () const |
| unireg.cc will call this to make sure that the storage engine can handle the data it is about to send. Return real limits of your storage engine here; MySQL will do min(your_limits, MySQL_limits) automatically. | |
| uint | max_supported_key_parts () const |
| unireg.cc will call this to make sure that the storage engine can handle the data it is about to send. Return real limits of your storage engine here; MySQL will do min(your_limits, MySQL_limits) automatically. | |
| uint | max_supported_key_length () const |
| unireg.cc will call this to make sure that the storage engine can handle the data it is about to send. Return real limits of your storage engine here; MySQL will do min(your_limits, MySQL_limits) automatically. | |
| virtual double | scan_time () |
| Called in test_quick_select to determine if indexes should be used. | |
| virtual double | read_time (uint, uint, ha_rows rows) |
| This method will never be called if you do not implement indexes. | |
| int | open (const char *name, int mode, uint test_if_locked) |
| We implement this in ha_example.cc; it's a required method. | |
| int | close (void) |
| We implement this in ha_example.cc; it's a required method. | |
| int | write_row (uchar *buf) |
| We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented. | |
| int | update_row (const uchar *old_data, uchar *new_data) |
| We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented. | |
| int | delete_row (const uchar *buf) |
| We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented. | |
| int | index_read_map (uchar *buf, const uchar *key, key_part_map keypart_map, enum ha_rkey_function find_flag) |
| We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented. | |
| int | index_next (uchar *buf) |
| We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented. | |
| int | index_prev (uchar *buf) |
| We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented. | |
| int | index_first (uchar *buf) |
| We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented. | |
| int | index_last (uchar *buf) |
| We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented. | |
| int | rnd_init (bool scan) |
| Unlike index_init(), rnd_init() can be called two consecutive times without rnd_end() in between (it only makes sense if scan=1). In this case, the second call should prepare for the new table scan (e.g if rnd_init() allocates the cursor, the second call should position the cursor to the start of the table; no need to deallocate and allocate it again. This is a required method. | |
| int | rnd_end () |
| int | rnd_next (uchar *buf) |
| required | |
| int | rnd_pos (uchar *buf, uchar *pos) |
| required | |
| void | position (const uchar *record) |
| required | |
| int | info (uint) |
| required | |
| int | extra (enum ha_extra_function operation) |
| extra() is called whenever the server wishes to send a hint to the storage engine. The myisam engine implements the most hints. ha_innodb.cc has the most exhaustive list of these hints. | |
| int | external_lock (THD *thd, int lock_type) |
| required | |
| int | delete_all_rows (void) |
| Used to delete all rows in a table, including cases of truncate and cases where the optimizer realizes that all rows will be removed as a result of an SQL statement. | |
| int | truncate () |
| Used for handler specific truncate table. The table is locked in exclusive mode and handler is responsible for reseting the auto- increment counter. | |
| ha_rows | records_in_range (uint inx, key_range *min_key, key_range *max_key) |
| Given a starting key and an ending key, estimate the number of rows that will exist between the two keys. | |
| int | delete_table (const char *from) |
| Used to delete a table. By the time delete_table() has been called all opened references to this table will have been closed (and your globally shared references released). The variable name will just be the name of the table. You will need to remove any files you have created at this point. | |
| int | rename_table (const char *from, const char *to) |
| Renames a table from one name to another via an alter table call. | |
| int | create (const char *name, TABLE *form, HA_CREATE_INFO *create_info) |
| required | |
| THR_LOCK_DATA ** | store_lock (THD *thd, THR_LOCK_DATA **to, enum thr_lock_type lock_type) |
| required | |
 Public Member Functions inherited from handler | |
| virtual void | unbind_psi () |
| virtual void | rebind_psi () |
| handler (handlerton *ht_arg, TABLE_SHARE *share_arg) | |
| virtual handler * | clone (const char *name, MEM_ROOT *mem_root) |
| void | init () |
| int | ha_open (TABLE *table, const char *name, int mode, int test_if_locked) |
| Open database-handler. | |
| int | ha_close (void) |
| int | ha_index_init (uint idx, bool sorted) |
| int | ha_index_end () |
| int | ha_rnd_init (bool scan) |
| int | ha_rnd_end () |
| int | ha_rnd_next (uchar *buf) |
| int | ha_rnd_pos (uchar *buf, uchar *pos) |
| int | ha_index_read_map (uchar *buf, const uchar *key, key_part_map keypart_map, enum ha_rkey_function find_flag) |
| int | ha_index_read_last_map (uchar *buf, const uchar *key, key_part_map keypart_map) |
| int | ha_index_read_idx_map (uchar *buf, uint index, const uchar *key, key_part_map keypart_map, enum ha_rkey_function find_flag) |
| int | ha_index_next (uchar *buf) |
| int | ha_index_prev (uchar *buf) |
| int | ha_index_first (uchar *buf) |
| int | ha_index_last (uchar *buf) |
| int | ha_index_next_same (uchar *buf, const uchar *key, uint keylen) |
| int | ha_index_read (uchar *buf, const uchar *key, uint key_len, enum ha_rkey_function find_flag) |
| int | ha_index_read_last (uchar *buf, const uchar *key, uint key_len) |
| int | ha_reset () |
| Check handler usage and reset state of file to after 'open'. | |
| int | ha_index_or_rnd_end () |
| Table_flags | ha_table_flags () const |
| int | ha_external_lock (THD *thd, int lock_type) |
| int | ha_write_row (uchar *buf) |
| int | ha_update_row (const uchar *old_data, uchar *new_data) |
| int | ha_delete_row (const uchar *buf) |
| void | ha_release_auto_increment () |
| int | check_collation_compatibility () |
| int | ha_check_for_upgrade (HA_CHECK_OPT *check_opt) |
| int | ha_check (THD *thd, HA_CHECK_OPT *check_opt) |
| int | ha_repair (THD *thd, HA_CHECK_OPT *check_opt) |
| void | ha_start_bulk_insert (ha_rows rows) |
| int | ha_end_bulk_insert () |
| int | ha_bulk_update_row (const uchar *old_data, uchar *new_data, uint *dup_key_found) |
| int | ha_delete_all_rows () |
| int | ha_truncate () |
| int | ha_reset_auto_increment (ulonglong value) |
| int | ha_optimize (THD *thd, HA_CHECK_OPT *check_opt) |
| int | ha_analyze (THD *thd, HA_CHECK_OPT *check_opt) |
| bool | ha_check_and_repair (THD *thd) |
| int | ha_disable_indexes (uint mode) |
| int | ha_enable_indexes (uint mode) |
| int | ha_discard_or_import_tablespace (my_bool discard) |
| int | ha_rename_table (const char *from, const char *to) |
| int | ha_delete_table (const char *name) |
| void | ha_drop_table (const char *name) |
| int | ha_create (const char *name, TABLE *form, HA_CREATE_INFO *info) |
| int | ha_create_handler_files (const char *name, const char *old_name, int action_flag, HA_CREATE_INFO *info) |
| int | ha_change_partitions (HA_CREATE_INFO *create_info, const char *path, ulonglong *const copied, ulonglong *const deleted, const uchar *pack_frm_data, size_t pack_frm_len) |
| int | ha_drop_partitions (const char *path) |
| int | ha_rename_partitions (const char *path) |
| void | adjust_next_insert_id_after_explicit_value (ulonglong nr) |
| int | update_auto_increment () |
| virtual void | print_error (int error, myf errflag) |
| virtual bool | get_error_message (int error, String *buf) |
| uint | get_dup_key (int error) |
| virtual bool | get_foreign_dup_key (char *child_table_name, uint child_table_name_len, char *child_key_name, uint child_key_name_len) |
| virtual void | change_table_ptr (TABLE *table_arg, TABLE_SHARE *share) |
| virtual double | index_only_read_time (uint keynr, double records) |
| virtual longlong | get_memory_buffer_size () const |
| virtual ha_rows | multi_range_read_info_const (uint keyno, RANGE_SEQ_IF *seq, void *seq_init_param, uint n_ranges, uint *bufsz, uint *flags, Cost_estimate *cost) |
| virtual ha_rows | multi_range_read_info (uint keyno, uint n_ranges, uint keys, uint *bufsz, uint *flags, Cost_estimate *cost) |
| virtual int | multi_range_read_init (RANGE_SEQ_IF *seq, void *seq_init_param, uint n_ranges, uint mode, HANDLER_BUFFER *buf) |
| virtual int | multi_range_read_next (char **range_info) |
| virtual const key_map * | keys_to_use_for_scanning () |
| bool | has_transactions () |
| virtual uint | extra_rec_buf_length () const |
| virtual bool | is_fatal_error (int error, uint flags) |
| virtual ha_rows | records () |
| virtual ha_rows | estimate_rows_upper_bound () |
| virtual enum row_type | get_row_type () const |
| virtual void | column_bitmaps_signal () |
| MySQL signal that it changed the column bitmap. | |
| uint | get_index (void) const |
| virtual bool | start_bulk_update () |
| virtual bool | start_bulk_delete () |
| virtual int | exec_bulk_update (uint *dup_key_found) |
| virtual void | end_bulk_update () |
| virtual int | end_bulk_delete () |
| virtual int | read_range_first (const key_range *start_key, const key_range *end_key, bool eq_range, bool sorted) |
| Read first row between two ranges. Store ranges for future calls to read_range_next. | |
| virtual int | read_range_next () |
| Read next row between two endpoints. | |
| void | set_end_range (const key_range *range, enum_range_scan_direction direction) |
| int | compare_key (key_range *range) |
| int | compare_key_icp (const key_range *range) const |
| virtual int | ft_init () |
| void | ft_end () |
| virtual FT_INFO * | ft_init_ext (uint flags, uint inx, String *key) |
| virtual int | ft_read (uchar *buf) |
| virtual int | rnd_pos_by_record (uchar *record) |
| virtual int | read_first_row (uchar *buf, uint primary_key) |
| virtual int | restart_rnd_next (uchar *buf, uchar *pos) |
| virtual int | rnd_same (uchar *buf, uint inx) |
| virtual void | get_dynamic_partition_info (PARTITION_STATS *stat_info, uint part_id) |
| virtual uint32 | calculate_key_hash_value (Field **field_array) |
| virtual int | extra_opt (enum ha_extra_function operation, ulong cache_size) |
| virtual bool | start_read_removal (void) |
| virtual ha_rows | end_read_removal (void) |
| virtual bool | was_semi_consistent_read () |
| virtual void | try_semi_consistent_read (bool) |
| virtual void | unlock_row () |
| virtual int | start_stmt (THD *thd, thr_lock_type lock_type) |
| virtual void | get_auto_increment (ulonglong offset, ulonglong increment, ulonglong nb_desired_values, ulonglong *first_value, ulonglong *nb_reserved_values) |
| void | set_next_insert_id (ulonglong id) |
| void | restore_auto_increment (ulonglong prev_insert_id) |
| virtual void | update_create_info (HA_CREATE_INFO *create_info) |
| int | check_old_types () |
| virtual int | assign_to_keycache (THD *thd, HA_CHECK_OPT *check_opt) |
| virtual int | preload_keys (THD *thd, HA_CHECK_OPT *check_opt) |
| virtual int | indexes_are_disabled (void) |
| virtual char * | update_table_comment (const char *comment) |
| virtual void | append_create_info (String *packet) |
| virtual bool | is_fk_defined_on_table_or_index (uint index) |
| virtual char * | get_foreign_key_create_info () |
| virtual bool | can_switch_engines () |
| virtual int | get_foreign_key_list (THD *thd, List< FOREIGN_KEY_INFO > *f_key_list) |
| virtual int | get_parent_foreign_key_list (THD *thd, List< FOREIGN_KEY_INFO > *f_key_list) |
| virtual uint | referenced_by_foreign_key () |
| virtual void | init_table_handle_for_HANDLER () |
| virtual void | free_foreign_key_create_info (char *str) |
| virtual int | get_default_no_partitions (HA_CREATE_INFO *info) |
| virtual void | set_auto_partitions (partition_info *part_info) |
| virtual bool | get_no_parts (const char *name, uint *no_parts) |
| virtual void | set_part_info (partition_info *part_info, bool early) |
| uint | max_record_length () const |
| uint | max_keys () const |
| uint | max_key_parts () const |
| uint | max_key_length () const |
| uint | max_key_part_length () const |
| virtual uint | max_supported_key_part_length () const |
| virtual uint | min_record_length (uint options) const |
| virtual bool | low_byte_first () const |
| virtual uint | checksum () const |
| virtual bool | is_crashed () const |
| virtual bool | auto_repair () const |
| virtual uint | lock_count (void) const |
| virtual uint8 | table_cache_type () |
| virtual my_bool | register_query_cache_table (THD *thd, char *table_key, uint key_length, qc_engine_callback *engine_callback, ulonglong *engine_data) |
| Register a named table with a call back function to the query cache. | |
| virtual bool | primary_key_is_clustered () |
| virtual int | cmp_ref (const uchar *ref1, const uchar *ref2) |
| virtual const Item * | cond_push (const Item *cond) |
| virtual void | cond_pop () |
| virtual Item * | idx_cond_push (uint keyno, Item *idx_cond) |
| virtual void | cancel_pushed_idx_cond () |
| virtual uint | number_of_pushed_joins () const |
| virtual const TABLE * | root_of_pushed_join () const |
| virtual const TABLE * | parent_of_pushed_join () const |
| virtual int | index_read_pushed (uchar *buf, const uchar *key, key_part_map keypart_map) |
| virtual int | index_next_pushed (uchar *buf) |
| virtual bool | check_if_incompatible_data (HA_CREATE_INFO *create_info, uint table_changes) |
| virtual enum_alter_inplace_result | check_if_supported_inplace_alter (TABLE *altered_table, Alter_inplace_info *ha_alter_info) |
| bool | ha_prepare_inplace_alter_table (TABLE *altered_table, Alter_inplace_info *ha_alter_info) |
| bool | ha_inplace_alter_table (TABLE *altered_table, Alter_inplace_info *ha_alter_info) |
| bool | ha_commit_inplace_alter_table (TABLE *altered_table, Alter_inplace_info *ha_alter_info, bool commit) |
| void | ha_notify_table_changed () |
| virtual void | use_hidden_primary_key () |
| virtual uint | alter_table_flags (uint flags) |
| virtual int | bulk_update_row (const uchar *old_data, uchar *new_data, uint *dup_key_found) |
| virtual int | reset_auto_increment (ulonglong value) |
| virtual int | optimize (THD *thd, HA_CHECK_OPT *check_opt) |
| virtual int | analyze (THD *thd, HA_CHECK_OPT *check_opt) |
| virtual bool | check_and_repair (THD *thd) |
| virtual int | disable_indexes (uint mode) |
| virtual int | enable_indexes (uint mode) |
| virtual int | discard_or_import_tablespace (my_bool discard) |
| virtual void | drop_table (const char *name) |
| virtual int | create_handler_files (const char *name, const char *old_name, int action_flag, HA_CREATE_INFO *info) |
| virtual int | change_partitions (HA_CREATE_INFO *create_info, const char *path, ulonglong *const copied, ulonglong *const deleted, const uchar *pack_frm_data, size_t pack_frm_len) |
| virtual int | drop_partitions (const char *path) |
| virtual int | rename_partitions (const char *path) |
| virtual bool | set_ha_share_ref (Handler_share **arg_ha_share) |
| int | get_lock_type () const |
Additional Inherited Members | |
| Public Types inherited from handler | |
| enum | enum_range_scan_direction { RANGE_SCAN_ASC, RANGE_SCAN_DESC } |
| enum | { NONE = 0, INDEX, RND } |
| typedef ulonglong | Table_flags |
| Static Public Member Functions inherited from Sql_alloc | |
| static void * | operator new (size_t size) throw () |
| static void * | operator new[] (size_t size) throw () |
| static void * | operator new[] (size_t size, MEM_ROOT *mem_root) throw () |
| static void * | operator new (size_t size, MEM_ROOT *mem_root) throw () |
| static void | operator delete (void *ptr, size_t size) |
| static void | operator delete (void *ptr, MEM_ROOT *mem_root) |
| static void | operator delete[] (void *ptr, MEM_ROOT *mem_root) |
| static void | operator delete[] (void *ptr, size_t size) |
| Public Attributes inherited from handler | |
| handlerton * | ht |
| uchar * | ref |
| uchar * | dup_ref |
| ha_statistics | stats |
| range_seq_t | mrr_iter |
| RANGE_SEQ_IF | mrr_funcs |
| HANDLER_BUFFER * | multi_range_buffer |
| uint | ranges_in_seq |
| bool | mrr_is_output_sorted |
| bool | mrr_have_range |
| KEY_MULTI_RANGE | mrr_cur_range |
| key_range * | end_range |
| uint | errkey |
| uint | key_used_on_scan |
| uint | active_index |
| uint | ref_length |
| FT_INFO * | ft_handler |
| enum handler:: { ... } | inited |
| bool | implicit_emptied |
| const Item * | pushed_cond |
| Item * | pushed_idx_cond |
| uint | pushed_idx_cond_keyno |
| ulonglong | next_insert_id |
| ulonglong | insert_id_for_cur_row |
| Discrete_interval | auto_inc_interval_for_cur_row |
| uint | auto_inc_intervals_count |
| PSI_table * | m_psi |
| Protected Member Functions inherited from handler | |
| virtual int | index_read_idx_map (uchar *buf, uint index, const uchar *key, key_part_map keypart_map, enum ha_rkey_function find_flag) |
| Positions an index cursor to the index specified in argument. Fetches the row if available. If the key value is null, begin at the first key of the index. | |
| virtual int | index_next_same (uchar *buf, const uchar *key, uint keylen) |
| virtual int | index_read_last_map (uchar *buf, const uchar *key, key_part_map keypart_map) |
| The following functions works like index_read, but it find the last row with the current key value or prefix. | |
| virtual bool | prepare_inplace_alter_table (TABLE *altered_table, Alter_inplace_info *ha_alter_info) |
| virtual bool | inplace_alter_table (TABLE *altered_table, Alter_inplace_info *ha_alter_info) |
| virtual bool | commit_inplace_alter_table (TABLE *altered_table, Alter_inplace_info *ha_alter_info, bool commit) |
| virtual void | notify_table_changed () |
| void | ha_statistic_increment (ulonglong SSV::*offset) const |
| void ** | ha_data (THD *) const |
| THD * | ha_thd (void) const |
| PSI_table_share * | ha_table_share_psi (const TABLE_SHARE *share) const |
| virtual int | index_read (uchar *buf, const uchar *key, uint key_len, enum ha_rkey_function find_flag) |
| virtual int | index_read_last (uchar *buf, const uchar *key, uint key_len) |
| Handler_share * | get_ha_share_ptr () |
| void | set_ha_share_ptr (Handler_share *arg_ha_share) |
| void | lock_shared_ha_data () |
| void | unlock_shared_ha_data () |
| Protected Attributes inherited from handler | |
| TABLE_SHARE * | table_share |
| TABLE * | table |
| Table_flags | cached_table_flags |
| ha_rows | estimation_rows_to_insert |
| KEY_PART_INFO * | range_key_part |
| bool | eq_range |
| bool | in_range_check_pushed_down |
Class definition for the storage engine.
Definition at line 58 of file ha_example.h.
|
virtual |
We implement this in ha_example.cc; it's a required method.
Closes a table.
Called from sql_base.cc, sql_select.cc, and table.cc. In sql_select.cc it is only used to close up temporary tables or during the process where a temporary table is converted over to being a myisam table.
For sql_base.cc look at close_data_tables().
Implements handler.
Definition at line 323 of file ha_example.cc.
|
virtual |
required
create() is called to create a database. The variable name will have the name of the table.
When create() is called you do not need to worry about opening the table. Also, the .frm file will have already been created so adjusting create_info is not necessary. You can overwrite the .frm file at this point if you wish to change the table definition, but there are no methods currently provided for doing so.
Called from handle.cc by ha_create_table().
Implements handler.
Definition at line 901 of file ha_example.cc.
|
virtual |
Used to delete all rows in a table, including cases of truncate and cases where the optimizer realizes that all rows will be removed as a result of an SQL statement.
Called from item_sum.cc by Item_func_group_concat::clear(), Item_sum_count_distinct::clear(), and Item_func_group_concat::clear(). Called from sql_delete.cc by mysql_delete(). Called from sql_select.cc by JOIN::reinit(). Called from sql_union.cc by st_select_lex_unit::exec().
Reimplemented from handler.
Definition at line 711 of file ha_example.cc.
| int ha_example::delete_row | ( | const uchar * | buf | ) |
We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented.
This will delete a row. buf will contain a copy of the row to be deleted. The server will call this right after the current row has been called (from either a previous rnd_nexT() or index call).
If you keep a pointer to the last row or can access a primary key it will make doing the deletion quite a bit easier. Keep in mind that the server does not guarantee consecutive deletions. ORDER BY clauses can be used.
Called in sql_acl.cc and sql_udf.cc to manage internal table information. Called in sql_delete.cc, sql_insert.cc, and sql_select.cc. In sql_select it is used for removing duplicates while in insert it is used for REPLACE calls.
Definition at line 424 of file ha_example.cc.
|
virtual |
Used to delete a table. By the time delete_table() has been called all opened references to this table will have been closed (and your globally shared references released). The variable name will just be the name of the table. You will need to remove any files you have created at this point.
If you do not implement this, the default delete_table() is called from handler.cc and it will delete all files with the file extensions returned by bas_ext().
Called from handler.cc by delete_table and ha_create_table(). Only used during create if the table_flag HA_DROP_BEFORE_CREATE was specified for the storage engine.
Reimplemented from handler.
Definition at line 832 of file ha_example.cc.
| int ha_example::external_lock | ( | THD * | thd, |
| int | lock_type | ||
| ) |
required
This create a lock on the table. If you are implementing a storage engine that can handle transacations look at ha_berkely.cc to see how you will want to go about doing this. Otherwise you should consider calling flock() here. Hint: Read the section "locking functions for mysql" in lock.cc to understand this.
Called from lock.cc by lock_external() and unlock_external(). Also called from sql_table.cc by copy_data_between_tables().
Definition at line 758 of file ha_example.cc.
|
virtual |
extra() is called whenever the server wishes to send a hint to the storage engine. The myisam engine implements the most hints. ha_innodb.cc has the most exhaustive list of these hints.
Reimplemented from handler.
Definition at line 685 of file ha_example.cc.
|
virtual |
We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented.
index_first() asks for the first key in the index.
Called from opt_range.cc, opt_sum.cc, sql_handler.cc, and sql_select.cc.
Reimplemented from handler.
Definition at line 494 of file ha_example.cc.
|
inlinevirtual |
This is a bitmap of flags that indicates how the storage engine implements indexes. The current index flags are documented in handler.h. If you do not implement indexes, just return zero here.
part is the key part to check. First key part is 0. If all_parts is set, MySQL wants to know the flags for the combined index, up to and including 'part'.
Implements handler.
Definition at line 110 of file ha_example.h.
|
virtual |
We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented.
index_last() asks for the last key in the index.
Called from opt_range.cc, opt_sum.cc, sql_handler.cc, and sql_select.cc.
Reimplemented from handler.
Definition at line 515 of file ha_example.cc.
|
virtual |
We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented.
Used to read forward through the index.
Reimplemented from handler.
Definition at line 457 of file ha_example.cc.
|
virtual |
We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented.
Used to read backwards through the index.
Reimplemented from handler.
Definition at line 473 of file ha_example.cc.
|
virtual |
We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented.
Positions an index cursor to the index specified in the handle. Fetches the row if available. If the key value is null, begin at the first key of the index.
Reimplemented from handler.
Definition at line 438 of file ha_example.cc.
|
virtual |
required
info() is used to return information to the optimizer. See my_base.h for the complete description.
Currently this table handler doesn't implement most of the fields really needed. SHOW also makes use of this data.
You will probably want to have the following in your code:
The reason is that the server will optimize for cases of only a single record. If, in a table scan, you don't know the number of records, it will probably be better to set records to two so you can return as many records as you need. Along with records, a few more variables you may wish to set are: records deleted data_file_length index_file_length delete_length check_time Take a look at the public variables in handler.h for more information.
Called in filesort.cc, ha_heap.cc, item_sum.cc, opt_sum.cc, sql_delete.cc, sql_delete.cc, sql_derived.cc, sql_select.cc, sql_select.cc, sql_select.cc, sql_select.cc, sql_select.cc, sql_show.cc, sql_show.cc, sql_show.cc, sql_show.cc, sql_table.cc, sql_union.cc, and sql_update.cc.
Implements handler.
Definition at line 669 of file ha_example.cc.
|
inlinevirtual |
unireg.cc will call this to make sure that the storage engine can handle the data it is about to send. Return real limits of your storage engine here; MySQL will do min(your_limits, MySQL_limits) automatically.
There is no need to implement ..._key_... methods if your engine doesn't support indexes.
Reimplemented from handler.
Definition at line 155 of file ha_example.h.
|
inlinevirtual |
unireg.cc will call this to make sure that the storage engine can handle the data it is about to send. Return real limits of your storage engine here; MySQL will do min(your_limits, MySQL_limits) automatically.
There is no need to implement ..._key_... methods if your engine doesn't support indexes.
Reimplemented from handler.
Definition at line 144 of file ha_example.h.
|
inlinevirtual |
unireg.cc will call this to make sure that the storage engine can handle the data it is about to send. Return real limits of your storage engine here; MySQL will do min(your_limits, MySQL_limits) automatically.
There is no need to implement ..._key_... methods if your engine doesn't support indexes.
Reimplemented from handler.
Definition at line 133 of file ha_example.h.
|
virtual |
We implement this in ha_example.cc; it's a required method.
Used for opening tables. The name will be the name of the file.
A table is opened when it needs to be opened; e.g. when a request comes in for a SELECT on the table (tables are not open and closed for each request, they are cached).
Called from handler.cc by handler::ha_open(). The server opens all tables by calling ha_open() which then calls the handler specific open().
Implements handler.
Definition at line 296 of file ha_example.cc.
|
virtual |
required
position() is called after each call to rnd_next() if the data needs to be ordered. You can do something like the following to store the position:
The server uses ref to store data. ref_length in the above case is the size needed to store current_position. ref is just a byte array that the server will maintain. If you are using offsets to mark rows, then current_position should be the offset. If it is a primary key like in BDB, then it needs to be a primary key.
Called from filesort.cc, sql_select.cc, sql_delete.cc, and sql_update.cc.
Implements handler.
Definition at line 599 of file ha_example.cc.
Given a starting key and an ending key, estimate the number of rows that will exist between the two keys.
end_key may be empty, in which case determine if start_key matches any rows.
Called from opt_range.cc by check_quick_keys().
Reimplemented from handler.
Definition at line 874 of file ha_example.cc.
|
virtual |
Renames a table from one name to another via an alter table call.
If you do not implement this, the default rename_table() is called from handler.cc and it will delete all files with the file extensions returned by bas_ext().
Called from sql_table.cc by mysql_rename_table().
Reimplemented from handler.
Definition at line 854 of file ha_example.cc.
|
virtual |
Unlike index_init(), rnd_init() can be called two consecutive times without rnd_end() in between (it only makes sense if scan=1). In this case, the second call should prepare for the new table scan (e.g if rnd_init() allocates the cursor, the second call should position the cursor to the start of the table; no need to deallocate and allocate it again. This is a required method.
rnd_init() is called when the system wants the storage engine to do a table scan. See the example in the introduction at the top of this file to see when rnd_init() is called.
Called from filesort.cc, records.cc, sql_handler.cc, sql_select.cc, sql_table.cc, and sql_update.cc.
Implements handler.
Definition at line 539 of file ha_example.cc.
|
virtual |
required
This is called for each row of the table scan. When you run out of records you should return HA_ERR_END_OF_FILE. Fill buff up with the row information. The Field structure for the table is the key to getting data into buf in a manner that will allow the server to understand it.
Called from filesort.cc, records.cc, sql_handler.cc, sql_select.cc, sql_table.cc, and sql_update.cc.
Implements handler.
Definition at line 566 of file ha_example.cc.
|
virtual |
required
This is like rnd_next, but you are given a position to use to determine the row. The position will be of the type that you stored in ref. You can use ha_get_ptr(pos,ref_length) to retrieve whatever key or position you saved when position() was called.
Called from filesort.cc, records.cc, sql_insert.cc, sql_select.cc, and sql_update.cc.
Implements handler.
Definition at line 619 of file ha_example.cc.
|
virtual |
required
The idea with handler::store_lock() is: The statement decides which locks should be needed for the table. For updates/deletes/inserts we get WRITE locks, for SELECT... we get read locks.
Before adding the lock into the table lock handler (see thr_lock.c), mysqld calls store lock with the requested locks. Store lock can now modify a write lock to a read lock (or some other lock), ignore the lock (if we don't want to use MySQL table locks at all), or add locks for many tables (like we do when we are using a MERGE handler).
Berkeley DB, for example, changes all WRITE locks to TL_WRITE_ALLOW_WRITE (which signals that we are doing WRITES, but are still allowing other readers and writers).
When releasing locks, store_lock() is also called. In this case one usually doesn't have to do anything.
In some exceptional cases MySQL may send a request for a TL_IGNORE; This means that we are requesting the same lock as last time and this should also be ignored. (This may happen when someone does a flush table when we have opened a part of the tables, in which case mysqld closes and reopens the tables and tries to get the same locks at last time). In the future we will probably try to remove this.
Called from lock.cc by get_lock_data().
Implements handler.
Definition at line 802 of file ha_example.cc.
|
virtual |
Used for handler specific truncate table. The table is locked in exclusive mode and handler is responsible for reseting the auto- increment counter.
Called from Truncate_statement::handler_truncate. Not used if the handlerton supports HTON_CAN_RECREATE, unless this engine can be used as a partition. In this case, it is invoked when a particular partition is to be truncated.
Reimplemented from handler.
Definition at line 734 of file ha_example.cc.
| int ha_example::update_row | ( | const uchar * | old_data, |
| uchar * | new_data | ||
| ) |
We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented.
Yes, update_row() does what you expect, it updates a row. old_data will have the previous row record in it, while new_data will have the newest data in it. Keep in mind that the server can do updates based on ordering if an ORDER BY clause was used. Consecutive ordering is not guaranteed.
Currently new_data will not have an updated auto_increament record. You can do this for example by doing:
Called from sql_select.cc, sql_acl.cc, sql_update.cc, and sql_insert.cc.
Definition at line 396 of file ha_example.cc.
| int ha_example::write_row | ( | uchar * | buf | ) |
We implement this in ha_example.cc. It's not an obligatory method; skip it and and MySQL will treat it as not implemented.
write_row() inserts a row. No extra() hint is given currently if a bulk load is happening. buf() is a byte array of data. You can use the field information to extract the data from the native byte array type.
Example of this would be:
See ha_tina.cc for an example of extracting all of the data as strings. ha_berekly.cc has an example of how to store it intact by "packing" it for ha_berkeley's own native storage type.
See the note for update_row() on auto_increments. This case also applies to write_row().
Called from item_sum.cc, item_sum.cc, sql_acl.cc, sql_insert.cc, sql_insert.cc, sql_select.cc, sql_table.cc, sql_udf.cc, and sql_update.cc.
Definition at line 360 of file ha_example.cc.
1.8.1.2
