Represents a connection to a cluster of storage nodes. More...

#include <ndb_cluster_connection.hpp>

Inheritance diagram for Ndb_cluster_connection:

Public Member Functions
	Ndb_cluster_connection (const char *connectstring=0)
	Ndb_cluster_connection (const char *connectstring, int force_api_nodeid)
	Ndb_cluster_connection (const char connectstring, Ndb_cluster_connection main_connection)
void	set_name (const char *name)
int	set_timeout (int timeout_ms)
int	connect (int no_retries=0, int retry_delay_in_seconds=1, int verbose=0)
int	start_connect_thread (int(*connect_callback)(void)=0)
int	wait_until_ready (int timeout_for_first_alive, int timeout_after_first_alive)
void	lock_ndb_objects ()
void	unlock_ndb_objects ()
const Ndb *	get_next_ndb_object (const Ndb *p)
int	get_latest_error () const
const char *	get_latest_error_msg () const
void	set_auto_reconnect (int value)
int	get_auto_reconnect () const
Uint32	collect_client_stats (Uint64 *statsArr, Uint32 sz)
int	get_no_ready ()
const char *	get_connectstring (char *buf, int buf_sz) const
int	get_connected_port () const
const char *	get_connected_host () const
void	set_optimized_node_selection (int val)
unsigned	no_db_nodes ()
unsigned	max_nodegroup ()
unsigned	node_id ()
unsigned	get_connect_count () const
unsigned	get_min_db_version () const
void	init_get_next_node (Ndb_cluster_connection_node_iter &iter)
unsigned int	get_next_node (Ndb_cluster_connection_node_iter &iter)
unsigned int	get_next_alive_node (Ndb_cluster_connection_node_iter &iter)
unsigned	get_active_ndb_objects () const
Uint64 *	get_latest_trans_gci ()

Friends
class	Ndb
class	NdbImpl
class	Ndb_cluster_connection_impl
class	SignalSender

Detailed Description

Represents a connection to a cluster of storage nodes.

Any NDB application program should begin with the creation of a single Ndb_cluster_connection object, and should make use of one and only one Ndb_cluster_connection. The application connects to a cluster management server when this object's connect() method is called. By using the wait_until_ready() method it is possible to wait for the connection to reach one or more storage nodes.

Definition at line 49 of file ndb_cluster_connection.hpp.

Constructor & Destructor Documentation

Ndb_cluster_connection::Ndb_cluster_connection ( const char * connectstring = 0 )

Create a connection to a cluster of storage nodes

Parameters

connectstring The connectstring for where to find the management server

Definition at line 48 of file ndb_cluster_connection.cpp.

Ndb_cluster_connection::Ndb_cluster_connection	(	const char *	connectstring,
		int	force_api_nodeid
	)

Create a connection to a cluster of storage nodes

Parameters

connectstring	The connectstring for where to find the management server
force_api_node	The nodeid to use for this API node, will override any nodeid=<nodeid> specified in connectstring

Definition at line 53 of file ndb_cluster_connection.cpp.

Member Function Documentation

Uint32 Ndb_cluster_connection::collect_client_stats	(	Uint64 *	statsArr,
		Uint32	sz
	)

Collect client statistics for all Ndb objects in this connection Note that this locks the ndb objects while collecting data.

See Ndb::ClientStatistics for suggested array size and offset meanings

Parameters

statsArr	Pointer to array of Uint64 values for stats
szz	Size of array

Returns: Number of stats array values written

Definition at line 952 of file ndb_cluster_connection.cpp.

Here is the call graph for this function:

int Ndb_cluster_connection::connect	(	int	no_retries = `0`,
		int	retry_delay_in_seconds = `1`,
		int	verbose = `0`
	)

Connect to a cluster management server

Parameters

no_retries	specifies the number of retries to attempt in the event of connection failure; a negative value will result in the attempt to connect being repeated indefinitely
retry_delay_in_seconds	specifies how often retries should be performed
verbose	specifies if the method should print a report of its progess

Returns: 0 = success, 1 = recoverable error, -1 = non-recoverable error

Definition at line 873 of file ndb_cluster_connection.cpp.

const Ndb * Ndb_cluster_connection::get_next_ndb_object ( const Ndb * p )

Iterator of ndb-objects

Parameters

p	Pointer to last returned ndb-object NULL - returns first object

Note: lock_ndb_objects should be used before using this function and unlock_ndb_objects should be used after

Definition at line 515 of file ndb_cluster_connection.cpp.

Here is the caller graph for this function:

void Ndb_cluster_connection::lock_ndb_objects ( )

Lock creation of ndb-objects Needed to iterate over created ndb objects

Definition at line 503 of file ndb_cluster_connection.cpp.

Here is the caller graph for this function:

void Ndb_cluster_connection::set_auto_reconnect ( int value )

Enable/disable auto-reconnect

Parameters

value 0 = false, 1 = true

Definition at line 946 of file ndb_cluster_connection.cpp.

void Ndb_cluster_connection::set_name ( const char * name )

Set a name on the connection, which will be reported in cluster log

Parameters

name

Definition at line 797 of file ndb_cluster_connection.cpp.

int Ndb_cluster_connection::set_timeout ( int timeout_ms )

Set timeout

Used as a timeout when talking to the management server, helps limit the amount of time that we may block when connecting

Basically just calls ndb_mgm_set_timeout(h,ms).

The default is 30 seconds.

Parameters

timeout_ms millisecond timeout. As with ndb_mgm_set_timeout, only increments of 1000 are really supported, with not to much gaurentees about calls completing in any hard amount of time.

Returns: 0 on success

Definition at line 933 of file ndb_cluster_connection.cpp.

Here is the call graph for this function:

void Ndb_cluster_connection::unlock_ndb_objects ( )

Unlock creation of ndb-objects

Definition at line 509 of file ndb_cluster_connection.cpp.

Here is the caller graph for this function:

int Ndb_cluster_connection::wait_until_ready	(	int	timeout_for_first_alive,
		int	timeout_after_first_alive
	)

Wait until the requested connection with one or more storage nodes is successful

Parameters

timeout_for_first_alive	Number of seconds to wait until first live node is detected
timeout_after_first_alive	Number of seconds to wait after first live node is detected

Returns: = 0 all nodes live, > 0 at least one node live, < 0 error

Definition at line 286 of file ndb_cluster_connection.cpp.

Here is the caller graph for this function:

Friends And Related Function Documentation

friend class Ndb

friend

Reciver(s)

Definition at line 206 of file ndb_cluster_connection.hpp.

The documentation for this class was generated from the following files:

storage/ndb/include/ndbapi/ndb_cluster_connection.hpp
storage/ndb/src/ndbapi/ndb_cluster_connection.cpp
